Micro USB OTG HUB AND RJ45 LAN Adapter for Raspberry Pi Zero

£5.80
Micro USB OTG HUB AND RJ45 LAN Adapter for Raspberry Pi Zero
The perfect way to add USB ports and network connectivity to your Raspberry Pi Zero or Model A+.
Expand the connectivity of your Pi allowing you to connect keyboards, mice, WiFi dongles, and other USB devices while also having a super-handy Ethernet port for wired network connectivity. It is robustly constructed with good cable strain relief.
You can expect around 12MB/s throughput from the Ethernet port.
Features:
Compact and lightweight
Three port bus-powered USB 2.0 hub
USB 10/100 Ethernet adapter (~12MB/s on the Raspberry Pi)
Strong enclosure with cable strain relief
Weighs just 30 grams
1.Supports Raspberry Pi Zero
2. Comes with a micro USB connect for Pi Zero
3.Support system:Windows 98SE/ME/2000/XP, android, Macintosh OS 9.0 or upper version.
4.Connection Speed: 10M/100Mbps.
5.Operating voltage: 4.2-5.5V.
6.Power: 1W.
7.Operating Frequency: 48MHz/125MHz.
8.Operating temperature: -25 Centigrade ~ +70 Centigrade.
9.Storage temperature: -40 ~ 85 Centigrade
10.Relative Humidity: 10% ~ 80% (non-condensing).
11.Operating Current: 180MA/5V.

Features and Advantages:
1. Classical design, easy to use.
2. Compliant with Tablet computers, adjust to MAC os system,no driver required with Tablet computer.
3. Broadband network with USB interface data transmission, apply to the desktop and laptop computers.
4. Support hot swaps. 5. neutral English clamshell packaging carton.
6. This device complies with USB Specifications 2.0 and 1.1,and uses a USB type A connector to connector to the USB host device draws power from the USB host bus, therefore no external power supply is required..
7. Support full-duplex data flow control (IEEE802.3X).
8. Support Protocol: IEEE 802.3u standard.
9. Support Performance USBV1.1 standard,Support full-duplex and half-duplex transmission speed for 10 and 100 Mbps operation.
10. Interface: USB,RJ45. 12.1. Integrated Fast Ethernet MAC, Physical Chip and transceiver in one chip.
11. Supports 10 Mb/s and 100Mb/s N-Way Auto-negotiation operation..
12. Support all USB standard command..
13. Supports Suspend/Resume detection logic.
14. 18K bytes SRAM built in. (2K bytes for Tx buffer, and 16K bytes for Rx buffer).
15. Compliant with PCI revision 2.2.
16. Supports ACPI, PCI power management.
17. Compliant with PC99 standard.
18. With 3 port USB2.0 HUB, convenient design.
Package Content:
1 x Micro USB Ethernet LAN RJ45 Hub.
UK seller, quick dispatch.
Please see my other listings for Raspberry Pi and Arduino related products.

Raspberry Pi is a Trademark of the Raspberry Pi Foundation



Product ID: EP00292
