AMT1001 Resistance Humidity Sensor Module for Arduino Raspberry Pi

£5.50
AM1001 4.75V-5.25V Resistive Temperature And Humidity Sensor Module Probe

AM1001 temperature and humidity module, that is the product of the relative humidity sensor and circuit integration. Module supply voltage to the DC voltage, the relative humidity by the voltage output is calculated, the module has a high accuracy, high reliability, consistency, and with temperaturecompensation, to ensure the long-term stability, and easy to use and inexpensive, and is particularly suitable for demanding enterprise use of quality, cost requirements.

Technical parameters:
(1) supply voltage (Vin): DC 4.5-6V
(2) Current consumption: about 2mA (MAX 3mA)
(3) Operating temperature range: 0 ~ 50 degree
(4) Humidity range: 95% RH (non condensing)
(5) Humidity measuring range: 20 ~ 95% RH
(6) Storage temperature range: 0 ~ 50 degree
(7) Storage humidity range: 80% RH (non condensing)
(8) Humidity measurement accuracy: 5% RH (25 degree ,30-80% RH)
(9) Voltage output range: 0.6-2.85V the DC (corresponding to 20 ~ 95% RH)

(9) The standard humidity output voltage:
(Condition: at25 degree, Vin = 5.0V)
Relative humidity (% RH) 20 30 40 50 60 70 80 90 95
Package includes:
1 x  AM1001 Resistive Humidity Sensor Module

Raspberry Pi is a Trademark of the Raspberry Pi Foundation
Product ID: EP00363
